Thermal Spring Deep Resistivity Well Logging Equipment Hot Water Well Temperature Logger

JHQ - 2D is a digital logging system specially designed for the convenience of field work, which can connect with various kinds of pipe and log. Because this system uses a series of advanced technology, it improves the use of one ground-based instrument controlling one heavy logging probe into one ground-based instrument controlling various kinds of logging probe, it also includes the deep measurement, the power supply and so on. The instrument has a light weight and simple operation and maintenance, which can be connected to the tube type, which can be aseismatic, temperature-resistant, moistureproof and high reliability.

Parameter

1. The use of the environment:Power supply: 220V, 50 Hz;Using the environment temperature: -20℃ ~ 45℃;Using the environment humidity: 90% or less (45℃)

2.The depth measurement system:Depth measurement range: 0 ~ 9999.99 m;Depth resolution: 0.28 mm;Speed measurement range: 0 ~ 9999m/h;Deep optical pulse signal: 3600 pulses per meter

3.Signal transmission system: Bottom hole output signal: bipolar coding;Communication with the computer: RS232 or USB;The underground signal detection level: plus or minus 0.5 V ~ plus or minus 12V

4. Figure out the depth of the graph; 1:10; 1:50. 1:100. 1:0; 1, 50, 0, etc.

5. The drawing accuracy:8 points per millimeter (curve);64 pixels per square millimeter (image method)

Probe: Natural Gamma, LR, NR, SPR, SP, ........................................

Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching,designing,developing and producing oil treatment equipment.With it’s continuous drawing of lessons,unremitting innovation and borrowing of advanced technology form both at home and abroad,our company is now becoming a professional manufacturer of oil purifiers which are excellent in quality,capable of standing wear,complete in various styles.And it’s aviation,ship,railway,pharmacy and edible oil processing.Though highly acclaimed and favorably accepted by numerous customers and possessed of the right to import and export,to ensure the high quality of our products,we conduct our manufacturing in strict accordance with the standard JB/T5285-2001 by Ministry of Machine Building,standard DL/T521-2004 by Ministry of Power Industry.

Our main products range is geological equipment products (Drilling Rig, Geological, Prospecting, Welllogger, BoreholeCamera, Inclinometer)

We have persisted on the business idea of “Integrity Basis and Quality First” for the stable and constant development.We are making effort to develop together with customers from both domestic and abroad on the basis of reciprocity.Client,quality and service are our supreme target.
