    Hydraulic Down-the-hole drill rig ZGYX-5500 shallow hole surface drilling

    Ask Lasest Price
    Brand Name : GOLD
    Model Number : ZGYX-5500
    Certification : CE
    Delivery Time : 10 days
    Payment Terms : T/T, West union, L/C
    Supply Ability : 100 sets per month
    Price : EXW USD5000/set
    • Product Details
    • Company Profile

    Hydraulic Down-the-hole drill rig ZGYX-5500 shallow hole surface drilling

    Vivienne
    Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
    Email: gold04@hy-industry.com
    Mobile / Whatsapp:+86-15123029803
    Fax:+86-23-62940030 Skype:viviennecq
    [Drilling Rig | Geological | Prospecting | Welllogger | BoreholeCamera | Inclinometer]

    Product Description

    The ZGYX-5500 Hydraulic Rock Drill for all kinds of rock drill hole 65-102 mm. This is water and electricity, railway, transport, open mines, quarries, defense and various large-scale construction of drilling equipment.


    Features

    1,ZGYX-5500 Hydraulic Rock Drill openequipped with Hydraulic Rock Breaker rail and multi-directional propulsion.
    2,have a high efficiency of punching ,higher than comparable pneumatic drill car 1-1.5 times.
    3,low energy consumption, lower than comparable pneumatic Drill 1/3-2/3.
    4,Strong structure,Compact,through strong, off-road performance is good.
    5,easy, safe, no dust, low noise.
    6,automatic anti-card filler device reliability. (Optional).

    Specification

    Working Wind Pressure (Mpa)
    0.7 - 1.0
    Air Consumption(m3/min)
    6 - 8
    Bore Dia.(mm)
    65 - 102
    DTH-Hammer
    DZYG38Hydraulic Rock Drill
    Bore Depth.(m)
    15 - 20
    Pushing Length(mm)
    3660
    Length of Drilling Pole(mm)
    3660
    Drilling Pole Diameter(mm)
    T38 T45
    Max. Lifting Force(N)
    20000
    Pitch Angle of Boom (°)
    Up 50 Down 15
    Flexing Angle of Boom (°)
    Left 25 Right 35
    Climbing Ability (°)
    25
    Traveling speed(km/h)
    1.5 - 3
    Rotating Speed (rpm)
    0 - 200
    Swing Torque (N.m)
    750
    Total Weight (kg )
    11000 - 13000
    Dimensions(mm)
    12000×2350×2800
    Method Dust Abatement
    Dry-type Dust Container
    Matched Power
    Yuchai 4108 × 2
