2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine

Chongqing Gold Mechanical & Equipment Co., Ltd
Contact Now
    Buy cheap 2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine from wholesalers

    Buy cheap 2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine from wholesalers
    • Buy cheap 2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine from wholesalers

    2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine

    Ask Lasest Price
    Brand Name : Gold
    Certification : CE ISO9001:2008
    Model Number : xy-2b
    Price : EXW USD5000/set
    Delivery Time : 15 days after receiving deposit
    Payment Terms : T/T, L/C
    Supply Ability : 100 Sets/Month
    • Product Details
    • Company Profile

    2016 Sales!XY-2B core drilling rig, historic geophysical prospecting drilling machine

    Vivienne
    Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
    Email: gold04@hy-industry.com
    Mobile / Whatsapp:+86-15123029803
    Fax:+86-23-62940030 Skype:viviennecq
    [Drilling Rig | Geological | Prospecting | Welllogger | BoreholeCamera | Inclinometer]

    Hydraulic core drill machine

    Most popular model, multifunctional, powerful

    Product Description

    XY-2B drillrig derived from xy-2 drillrig, it not only keeps all performances of xy-2 drill, but also adds spindle inner hole diameter to 96mm. It is especially available for constructions of hydroelectric power station, highway, railroad and harbor etc. In common with xy-2 drill in all design but hydraulic chuck and rotary head modified.XY-2B-12.jpgXY-2B-10.jpg


    Specifaction
    Drilling capacity (m)Φ73 rod100
    Φ60 rod320
    Φ50 rod380
    Φ42 rod530
    Spindle speed(r/min)Forward57;99;157;217;270;470;742;1024
    Reverse45;212
    Max torque(Nm)3330
    Angle renge0-90°
    Spindle max pull force(KN)60
    Spindle stroke (mm)560
    Hoist max lift capacity with single rope (KN)30
    Spindle inner dia (mm)Φ96
    Oil pumpCBK1020/8 twin-gear pump
    Power unitElectric motorY180L-4,22kW
    Diesel engine395K2,19.85kW
    Inner dia of spindle (mm)2220×900×1880
    Drill weight(excluding power)(kg)1200

    Hot Sale Models

    GD-600 XYD-200YYXYX3 MDL-150


    Our Services

    Ⅰ.Warranty

    The main machine has 12-month warranty, excluding the wearing parts, we offer these parts with the lowest price for our customer.

    Ⅱ.Installation and Commissioning

    A.We provide our customers foundation and layout drawings after payment.

    B. If needed, we will send technical engineers to the Buyer’s site for supervision of erection and Commissioning. Expenses abroad should be paid by the buyer.

    Ⅲ. Inspection:

    A. Customer inspection in factory;

    B. Supplier offer pictures for inspection;

    C. The third party inspection appointed by Customers.

    Packaging & Shipping

    Package: Wooden Case or Plywood

    Deliverey: Container ship

    Our Company View

    diamond drilling machinewater drilling machine in india
