Downhole Seismic Velocity logging Survey System Shear Velocity Measurement with Geophone

The wave velocity test is suitable for determining the wave velocity of compression waves, shear waves or Rayleigh waves of various rock and soil bodies. The single hole method, cross hole method or surface wave method can be used according to the task requirements. The iron ball is used to hit the wooden board horizontally to cause movement between the board and the ground, which generates rich shear waves, so as to receive the shear waves propagating downward through the soil layer at different heights in the borehole. Because this vertical propagation path is close to the situation where natural formations propagate vertically upwards from bedrock, it is more useful for formation response analysis.

Transient multi-point Rayleigh wave exploration

Shallow reflection measurement

Shallow refraction measurement

Wave velocity (shear wave) measurement

Multi-wave high-density seismic imaging

Pile foundation inspection

Civil Engineering Quality Inspection

Frequent measurement at the site

Vibration blasting measurement

Downhole Seismic Velocity logging Survey System Shear Velocity Measurement with Geophone

Number of channels: 6

Sampling points:
1024 samples, 2048 samples, 4096 samples, 8192 samples, 16384 samples
Ground pulsation measurement 1M sample several files

Sampling Rate:
10μs, 25μs, 50μs, 100μs, 200μs, 500μs, 1ms, 2ms, 5ms, 10ms, 20ms
Ground pulsation measurement is available from 1ms to 200ms

A / D converter: 24 bits

Signal superposition enhancement: 32 bits

Dynamic range: 144dB
